SPECIFICATION
- Built-in multi LED special effect programs to let the LEDs coordinate with the strong output to perform more patterns, such as flame, explosion, water wave, etc. LED could be turn on separately without fog output under DMX operation mode and perform multi professional color macro effects. It can be used as an LED par effects.
- Special patented high pressure design characterizes RJ-3.0 with higher velocity fogging and more powerful blast similar to CO2 effects.
- Patented instant stop function let RJ-3.0 stop fogging very fast and present perfect effect.
- Special built-in OPT function for selecting output power.
- Every maximum fogging time can reach 15 seconds (maximum fogging volume)
- For hanging RJ-3.0 upside down, simply need to loosen the fixing ring and bottom panel of the fluid tank, and change the position of the tank.
- The machine can be installed for fogging up, down, or front.
- Built-in DMX. There are 6 DMX control modes for selection, which are 1-channel, 2-channel, 3-channel, 5-channel, 6-channel and 13-channel. Can easily work with any DMX controller.
- Manual fogging function is prior to any control mode.
- One piece heating module design of high efficiency prevents easy clogging.
- Supper output. Amazing output of about 85,000 cu.ft/min.
- Sensitive electronic thermostat system – Electronic thermostat system allows the heater to always keep certain temperature for every fogging cycle, make the heat cycle faster.
- Multi safety protection. The heater is protected with an iron case and two more protective layers of temperature.
- Omega quick remove supports are attached.
- Can be controlled by wireless controller RC-4CD, which is of simple and humanized design and makes RJ-3.0 easier to be used.
| Name | Raytheon Jet |
| Item No. | RJ-3.0 |
| Heater Power (230V) | 3000W |
| Consumption (230V) | 3280W |
| Fuse (230V) | NFB 23A |
| Power Connection (230V /240V) | PowerCON |
| Voltage | 230V, 240V, 50Hz |
| First Heating Time (min.) | 12 |
| Cyclic Heating Time (seconds) | 60 |
| Fog Output (cu.ft/min) | 85,000 |
| Maximum Injection Height | 12m/5 seconds |
| Maximum duration per output (100%Output) | 15 seconds |
| Fluid Consumption (ml/min) | 420 |
| LED | 8W x 41 (RGBA 4in 1) |
| Protocol | DMX512 |
| DMX Mode | 1CH,2CH,3CH,5CH,6CH,13CH, 6 modes |
| Display | LCD |
| DMX connections | 3P XLR & 5P XLR |
| Built-in Functions | OPT control, color macro |
| Manual Output | Yes |
| Pump Stop When No Fluid | Yes |
| No Fluid Warning | Yes, display indication |
| Patented Instant Stop Function | Yes |
| Patented High Pressure Output | Yes |
| Multi-level Discoloration | Yes |
| Tank (Liters) | 5.6L |
| Handle | Yes |
| Dimensions/mm(LxWxH W/Handle) | 523 x 364 x 321mm |
| Weight (kg) | 32.5kg |
| Matching Controller (Included) | RC-4CD |
