- Patented waterproof sealing box design. Control board and aluminum heater
block sealing box can achieve true waterproof level of IP67. - Ultra large thermal capacity is capable of continuous smoke.
- Extra-large smoke output of 60000 cu. ft/min with 0-100% output adjustment.
- Under the condition of 100% output, the continuous smoke spraying time is
35 seconds. - The entire machine with design of stainless-steel shell is resistant to corrosion
and various climates. - Anti-collision rubber corner protectors can protect the machine from damage.
- Intelligent touch screen design makes the operation display more intuitive,
and the operation level of special effect be completely elevated. - Two functional module slots allow all optional wireless control accessories to be
connected and controlled. - Multi functions of operation control including built-in timer, manual, external
controller, and DMX. - DMX on board, 3 DMX modes for choice; 1CH, 2CH, and 4CH. It is easy to use
any external DMX controllers. - Built in “No Fluid” automatic detection. If snow water runs out, the touch
screen will display a warning, and the machine will stop working. - With RDM (Remote Device Management) function. The address code, channel
mode, and monitoring device operation status of the machine can be remotely
controlled through the RDM bidirectional protocol control console. - It can be used with Remote series wired controller (optional), RF wireless
controller (optional), and wireless DMX for control. Simple and user-friendly
design makes IPF-1500 easier to be operated and used. - Designed with similar flight case structure for easy handling and transportation.
- With professional waterproof IP65 PowerCON True 1 power cord.
- It’s recommended to use our high-quality and environmentally friendly fog
liquid together to achieve the best effect.
| 名称 | Ambitious fog 1500IP |
| Model | IPF-1500 |
| Heater Power | 1500W |
| Consumption | 1600W |
| Fuse (120V True1) | NFB 250V 20A |
| Fuse (230V True1) | NFB 250V 10A |
| Initial Ready (min.) | 14 |
| Cyclic Heating (Sec.) | 99 |
| Smoke Angle | 25 degree |
| Built-in Preset | 5 timing fog modes |
| DMX Channels | 1,2,4 CH |
| Display | LCD Touch Screen |
| On Board Control | YES, Timeing Control |
| Primary/Salve | NO |
| Manual Fogging | YES |
| Warning/Pump Stop | YES |
| Operate with exterior controller | YES |
| Fluid Consumption Rate: | 200ml/min. |
| Max Continuous Output Duration (Sec.) | 35 |
| Fog Output ( m3/min & ft3/min ) | 1700m3/min (60000ft3/min) |
| Output Adjustment | 0-100% |
| Tank (Removable) | 5L |
| Hanging Bracket | YES |
| Card Input Slot | YES, 2 |
| DMX Connectors (3P or 5P XLR) | 5PIN |
| Remote Connect | 4PIN |
| Low Fluid Shutdown | NO |
| Size (LxWxH) | 648*337*411mm (Bracket included) |
| Weight (kg) | 25.8KG |
| Voltage | 230V50HZ / 120V60HZ |
| Control (optional) | NovRemote,NovRemote-V, NovRemote,-I,NovRemote-VIDI |
| Accessories (optional) | NovFly, NovRF, NovApp |
| IP Rating | IP67 |
